Dimension 166mm*166mm±0. 25mm
Diagonal 223mm±0.5mm
Thickness(Si) 190μm±30μm
Front 9 busbars(silver), width 0.1±0.03mm 124 finger grids Blue anti-reflecting coating(silicon nitride)
Back width of back electrode(silver) 1.3±0.25mm,finger grids(aluminum), dotted laser design
► Features
˃ High conversion efficiencies resulting in superior power output performance
˃ Outstanding power output even in low light or high temperature conditions
˃ Optimized design for ease of soldering and lamination
˃ Long-term stability, reliability and performance
˃ Low breakage rate
˃ Uniform Color
► Production and Quality Control
˃ Precision cell efficiency sorting procedures
˃ Stringent criteria for color uniformity and appearance
˃ Reverse current and shunt resistance screening
˃ ISO9001,ISO14001 and OHSAS 18001 certificated
˃ Calibrated against Fraunhofer ISE
